DONNÉES GÉNÉRALES |
Année du premier vol (ou de design, si seul projet) |
1954 |
Pays | Danemark |
Designer(s) | Polyteknisk Flyvegruppe |
Premier constructeur | Polyteknisk Flyvegruppe (DK) |
Type d'appareil | Planeur |
Fonction | Entraînement |
SPÉCIFICATIONS TECHNIQUES |
Envergure | 15.4 m |
Longueur | 8.5 m |
Hauteur | -- |
Allongement | 12.5 |
Surface alaire | 19 m2 |
Profil aile | Emplanture Clark Y 15.7%, milieu Clark Y 15.7%, saumon NACA 6412 |
Masse à vide | 280 kg |
Masse maxi | 460 kg |
Charge alaire | 24 kg/m2 |
Vitesse mini | 56 km/h |
Vitesse maxi | 140 km/h |
Finesse maxi | 23 à 65 km/h |
Taux de chute mini | 0.75 m/s à 60 km/h |
Nb sièges | 2 |
Structure | Fuselage en tubes d'acier soudés et entoilé. Ailes bois et toile. |
Liens WEB | Site : UIUC Applied Aerodynamics Group's . CLARK Y airfoil. (2011-11-20 JM) Site : UIUC Applied Aerodynamics Group's . CLARK Y fichier DAT. (2011-11-20 JM) Site : UIUC Applied Aerodynamics Group's . NACA 6412 airfoil. (2011-11-20 JM) Site : UIUC Applied Aerodynamics Group's . NACA 6412 fichier DAT. (2011-11-20 JM) Site : Polyteknisk Flyvegruppe . Note + photo [OY-XAG]. (2020-04-27 CL) Site : Facebook - Dansk Svæveflyvehistorisk Klub (DaSK) . Note + 6 photos. (2020-04-27 CL) |
Livres | Sailplanes 1945-1965 par SIMONS, Martin (2001) [p. 49-50. Note + 2 photos + plan 3 vues]. The World's Sailplanes II par OSTIV (1963) [p. 70-71. Photo + 3-vues + specs + texte]. |
