| DONNÉES GÉNÉRALES |
| Année du premier vol (ou de design, si seul projet) |
1948 |
| Pays | Yougoslavie |
| Designer(s) | CIJAN, Boris & OBAD, Stanko |
| Premier constructeur | Yugoslavian Aeronautical Union |
| Type d'appareil | Planeur |
| Fonction | Performance |
| SPÉCIFICATIONS TECHNIQUES |
| Envergure | 19 m |
| Longueur | 7 m |
| Hauteur | -- |
| Allongement | 20 |
| Surface alaire | 17.8 m2 |
| Profil aile | Göttingen 549 |
| Masse à vide | 365 kg |
| Masse maxi | 455 kg |
| Charge alaire | 25.5 kg/m2 |
| Vitesse mini | -- |
| Vitesse maxi | -- |
| Finesse maxi | 36 |
| Taux de chute mini | -- |
| Nb sièges | 1 |
| Structure | Bois et toile, et longeron d'aile en métal. |
| Liens WEB | Site : UIUC Applied Aerodynamics Group's . Göttingen 549 airfoil. (2009-11-29) Site : UIUC Applied Aerodynamics Group's . Göttingen 549 fichier DAT. (2009-11-29) Site : Airliners . YU-4096, musée de Belgrade. (2010-05-18 CL) Site : Forum Modelarji.com . plan 3 vues + photo. (2010-05-18 CL) Site : Forum Modelarji.com . Photo en vol (avec le Kosava). (2010-05-18 CL) |
| Livres | Sailplanes 1945-1965 par SIMONS, Martin (2001) [p. 139-141. Texte + 3 photos + plan 3 vues + specs]. |
|
Fiche n° 398 [Dernière mise à jour : 2023-12-17]
