Beatty-Johl BJ-1

DONNÉES GÉNÉRALES
Année du premier vol
(ou de design, si seul projet)
1953
Pays Afrique du Sud
Designer(s) BEATTY, Patrick James & JOHL, Wilfred A. Theodore (Fritz)
Premier constructeur Projet non abouti
Type d'appareil Planeur
Fonction Expérimental

SPÉCIFICATIONS TECHNIQUES
Envergure 15.4 m
Longueur 6.5 m
Hauteur--
Allongement--
Surface alaire13.9 m2
Profil aile--
Masse à vide340 kg
Masse maxi--
Charge alaire25.36 kg/m2
Vitesse mini--
Vitesse maxi--
Finesse maxi
Taux de chute mini--
Nb sièges1
StructureBois et toile

Hank THOR dans le planeur en cours de construction [via Michel Blanchard]
[Origine inconnue, via Michel Blanchard]

AUTRES INFORMATIONS

Constructeur(s)
ConstructeurConstruits
Performance Sailplanes, Patrick J. BEATTY (SA)
La construction du BJ-1 ne fut jamais terminée

0
Nombre total de constructionsProjet non abouti
Infos techniquesEmpennage en V
Histoire résuméeThe BJ-1
After the IWW, Patrick BEATTY returned to South Africa, and started Performance Sailplanes, with the idea to produce gliders locally. A licence was obtained to manufacture the Grunau Baby. Unfortunately, the hoped-for local market never materialised, and only one Baby was produced. In order to survive, commercial wood-turning work became the main activity of Performance Sailplanes.
Soon after the Grunau Baby was completed, Pat BEATTY and Fritz JOHL teamed up to design a world beating glider. The 'BJ-1' was designed in 1953, and the designers were confident that it was going to be a world-beater. Like all subsequent designs, the BJ- 1 was designed for South Africa's strong thermals - it had a very high wing loading for its time, and was equipped with trailing edge flaps to improve low speed flying.
The BJ-1 was never completed. Soon after the construction process started, the two designers came up with an even more radical design, the BJ-2.
Liens personnalitésBEATTY Patrick (Afrique du Sud)
JOHL Wilfred A. Theodore (Fritz) (Afrique du Sud)

SOURCES DOCUMENTAIRES

Liens WEBSite : Google Groups . Note. (2016-11-13 CL)
LivresPas de livre référencé.

MODÈLES RÉDUITS

Pas de plan ou kit référencé.
Fiche n° 4227 [Dernière mise à jour : 2017-04-19]
