Horten Ho-IV

DONNÉES GÉNÉRALES
Année du premier vol
(ou de design, si seul projet)
1939
Pays Allemagne
Designer(s) HORTEN, Walter & HORTEN, Reimar
Premier constructeur HORTEN, Walter & HORTEN, Reimar
Type d'appareil Aile volante
Fonction Performance

SPÉCIFICATIONS TECHNIQUES
Envergure 20 m
Longueur 3.8 m
Hauteur 1.1 m
Allongement20.9
Surface alaire19.1 m2
Profil aileSpécifique
Masse à vide240 kg
Masse maxi350 kg
Charge alaire18.35 kg/m2
Vitesse mini--
Vitesse maxi200 km/h
Finesse maxi37 à 80 km/h
Taux de chute mini0.5 m/s à 0.65 km/h
Nb sièges1
Structure--

[Flugzeug-Typenbuch, Ausgabe 1944 - collection J-M. Mesot]
[Flugzeug-Typenbuch, Ausgabe 1944 - collection J-M. Mesot]

AUTRES INFORMATIONS

Constructeur(s)
ConstructeurConstruits
HORTEN, Walter & HORTEN, Reimar--
Nombre total de constructions--
Infos techniques--
Histoire résumée--
Liens personnalitésHORTEN, Reimar (Allemagne)
HORTEN, Walter (Allemagne)

SOURCES DOCUMENTAIRES

Liens WEBSite : Site Coin de Ciel (Уголок неба) . Note + 3 photos + plan 3 vues + specs. (2009-10-30 CL)
Site : Nuricom (Klaus Niegratschka) . Plan 3 vues. (2011-04-13 CL)
Site : Nuricom (Klaus Niegratschka) . Plan 3 vues (Ho-IVA USA). (2011-04-13 CL)
Site : Page de Sascha Heuser . Construction d'une aile à l'échelle 1.. (2012-03-13)
Site : Projekt Horten IV . Können wir einen Horten-Nurflügel wieder in die Luft bringen ? Texte + photos. (2013-12-13 CL)
LivresFlugzeug-Typenbuch 1944
par SCHNEIDER, Helmut (1944) [p. 308, 309. Photo + 3-vues + specs].
Sailplanes 1920-1945
par SIMONS, Martin (2001) [p. 143. Photo + 3-vues + specs].
Autres sourcesSoaring mai 1964 p 29. Note + photo + specs.
The story of the Horten IV replica, par Bernd Ewald/Sascha Heuser, VGC News n° 137, printemps 2013, p 42-43. Texte + photos.

MODÈLES RÉDUITS

      Plan André Lambert
      Kit Auteur inconnu
Fiche n° 709 [Dernière mise à jour : 2010-04-03]
